20 m telescopic crank up antenna mast ham radio

FOB Reference Price:Get Latest Price
US $1,850-2,150 / Units | 1 Unit/Units 20 m telescopic antenna mast (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland)
Brand Name:
Talents
Model Number:
TAL-E20-3-15
total height:
20m
minum height:
3m
Material:
aluminium alloy
Surface:
hard anodized treatment
color:
black white blue etc
application:
Emergency Lighting, Military, Antenna, Mobile Communication Tower.
outer tube dia.:
30-130mm
max. payload:
15kg
thickness:
2mm to 4mm
wind load rating:
100m/h to 120km/h with guy wires
Supply Ability
Supply Ability:
200 Unit/Units per Month 20 m telescopic antenna mast
Packaging & Delivery
Packaging Details
packing of 20 m telescopic antenna mast: one set put into a plywood case
Port
China main port
Lead Time :
20days after the down payment
Detailed Images
20 m telescopic crank up antenna mast ham radio
Product Description
20 m telescopic crank up antenna mast ham radio
technical data
main spec.
Closed length:3m         (Bottom base included)
Extended length: 20m                  (Bottom base included)
Max loading:15kg or customized
Temperature: working temp:-40--+50C Storage Temp:-55--+70C
main pole in sections
Section No.           OD                            Thickness
1#:                        30mm                     2.0mm
2#:                        40mm                      2.0mm
3#:                        50mm                      2.0mm
4#:                        60mm                      2.0mm
5#:                        70mm                      2.0mm
6#:                        80mm                       2.0mm
7#:                        90mm                       2.0mm
8#                            105mm                     5.0mm
9#                             130mm                     4.0mm
Bottom base
diameter: 180mm                   Thickness: 12mm
Accessories
Pulling cord box with handle bars------------------3 units
Ground anchor------------------------------------------3 pieces
Handle lifting bar---------------------------------------2 pieces
304 stainless steel stakes-------------------------------6 pieces
Tripod -----------------------------------------------------1 piece
Top plate---------------------------------------------------1 piece
Material
Main Pole: aluminum alloy
Bottom base and accessories(except the stakes): iron steel
Pulling cord: stainless steel wire(OD:2mm)
Color
the whole unit will be in army green when closed, but when extended, the main pole will be in origin color of aluminum alloy only with top 4cm of each pole section in army green color.Technology: painting

kinds of antenna can be mounted on the top of mast

accessories

Pulling cord box with handle bars------------------3 units
Ground anchor------------------------------------------3 pieces
Handle lifting bar---------------------------------------2 pieces
304 stainless steel stakes-------------------------------6 pieces
Tripod -----------------------------------------------------1 piece
Top plate---------------------------------------------------1 piece

Packing & Delivery

20 m telescopic crank up antenna mast ham radio

Packing details
C/NO.
DESCRIPTION
QTY
(UNIT)
N.W.
(KG)
G.W.
(KG)
MEAS
(CM)
1
Pole : ------------------1 unit
accessories---------1 set
1
50.00
70.00
230*30*40
After-sale service
 Except the damages due to misuse,unauthorized modification and man-made sabotage,
the damaged of the telescopic mast will enjoyed free after-sales maintenance
within one year time from the date of delivery on the condition that the buyer
himself will bear the shipping cost back and forth and the said damage should be
confirmed by the seller through photos and description

Installation Instructions:
1)the  mast can be installed on the ground, or on the vehicle. No matter where to install, its installation shall keep vertical with the ground.Tilted telescopic  mast will affect the rise and fall of itself, and if the lifting rod tilts seriously or maintain a long time, damage and danger could not be avoided.

2)the mast needs to be installed on a fixed object, without any shaking, such as walls, car body, or pile. At least two fixed points will be installed, and one point must be installed on the body of the telescopic antenna mast. And the distance between two points should be longer than 2/3 of the height of telescopic  mast. Its connection must be solid and reliable.
Our Service
we supply telescopic mast up to 35m,usually used as antenna mast,communication tower,light support,camera mast and so on,custom-made payload to 400kg,customized length,retracted,payload etc. accepted.
catalog of some common grade manual mast as follows
extended height
(m)
No. of section
retracted height
(m)
outer tube range
(mm)
self weight
(kg)
4
3
1.6
60-80
14
5
4
1.65
50-80
17
6
5
1.7
50-90
21
8
6
1.8
40-90
24
10
7
1.95
30-90
26
12
7
2.2
30-90
28
15
8
2.45
30-105
33
18
9
2.7
30-130
47
20
9
2.95
30-130
55
22
9
3.15
30-130
58
25
10
3.4
30-150
72
30
10
3.85
30-150
84
