DOT 100lb propane cooking gas cylinder sizes

FOB Reference Price:Get Latest Price
US $70-90 / Pieces | 430 Piece/Pieces propane gas cylinder sizes (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Material:
Steel
Use:
liquified propane gas
Pressure:
Low
Place of Origin:
Tianjin, China (Mainland)
Brand Name:
talents propane gas cylinder sizes
Model Number:
02-TL-PRO-373-2.44-1.6
material:
HP325
Working Pressure:
1.6Mpa/240psi
Diameter:
375mm
Water Capacity:
108L/238LB
Wall Thickness:
2.44mm
Height:
1255mm
Color:
Customer's Requirement
Certification:
DOT Approval
Standard:
DOT-4BW
Application:
liquified propane gas storage
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month propane gas cylinder sizes
Packaging & Delivery
Packaging Details
propane gas cylinder sizes in bluk, in bag, in carton or at buyer's option
Port
Xingang of Tianjin
Lead Time :
Shipped in 30 days after payment
Video Description
Product Description

DOT 100lb propane cooking gas cylinder sizes


working pressure
1.6Mpa/240psi
Out diameter
375mm
height
1255mm
material
HP325
filling weight
100lb DOT4BW lpg cylinders
Wall thickness
2.44mm
Certificate
DOT approval
standard
DOT-4BW240
valve
CGA510 OPD valve
color
as your requirement
Other products
Lpg cylinder model
Lpg cylinder model
Water capacity (L)
Hight (in/mm)
Outside diameter (in/mm)
Standard
Working pressure (psi/Mpa)
LPG 95.4A-0
43.3
29.92/760
12.01/305
DOT-4BW240& TC-4BWM16
240/1.65
LPG 47.7A-0
21.6
17.99/457
12.01/305
DOT-4BA240& TC-4BWM16
240/1.65
LPG 118A-0
118
47.32/1202
15.75/400
DOT-4BW270
270/1.869
LPG 52.4-0
52.4
31.81/808
13.19/335
DOT-4BW270
270/1.869
LPG 38.1-0
38.1
26.30/668
12.84/326
DOT-4BW270
270/1.869
LPG 35.5A-0
35.5
25.00/635
12.84/326
DOT-4BW270
270/1.869
LPG 35.5-0
35.5
25.98/660
12.60/320
DOT-4BW270
270/1.869
LPG 33.4-0
33.4
23.54/598
12.60/320
DOT-4BW270
270/1.869
LPG 32.2A-0
32.2
22.72/577
12.37/314
DOT-4BW270
270/1.869
LPG 32.2-0
32.2
23.39/594
12.84/326
DOT-4BW270
270/1.869
LPG 31-0
31
22.99/584
12.84/326
DOT-4BW270
270/1.869
LPG 26.2-0
26.2
23.27/591
11.62/295
DOT-4BW270
270/1.869
LPG 23.8A-0
23.8
19.09/485
12.60/320
DOT-4BW270
270/1.869
LPG 23.5-0
23.5
18.19/462
13.39/340
DOT-4BW270
270/1.869
LPG 4.8C-0
4.8
11.65/296
7.80/198
DOT-4BW270
270/1.869
LPG 4.8B-0
4.8
12.28/312
8.86/225
DOT-4BW270
270/1.869
Product advantages


DOT certificate seal

DOT certificate seal shows the cylinder is America DOT certified, it including cylinder number, specification, manufature and retest time.

Anti-rust painting processing

 first by shot blasting, the base coat use Zinc-Oxide anti corrosive paint, followed by coating with Aliphatic Polyurethane

POL valve CGA510

Valve inlet thread 3/4’’-14 NGT,
Valve outlet thread 0.885’’-14-NGO-LH
Valve without Dip Tube
Valve working pressure: 2.2Mpa
Valve pressure relief range: 2.6-3.3Mpa
Valve material: Brass

CGA510 OPD valve with dip tube

Valve inlet thread 3/4’’-14 NGT,
Valve outlet thread 0.885’’-14-NGO-LH
Valve with dip Tube
Valve working pressure: 2.2Mpa
Valve pressure relief range: 2.6-3.3Mpa
Valve material: Brass

Certification

DOT 4BA 4BW is issued by the Department of Transportation of American(DOT)

TC 4BWM 4BAM is issued by the CSA department of Canada, it is also called Canada DOT

TPED certificate is for Europe market, it is also safety certificate on pressured vessel transportation

Production processin
Packing & Delivery

Packing: Each piece of the cylinder is packed with white mesh and then loaded in bulk into the 20GP/40HQ container
Delivery: About 50 days after receiving your down payment

Our Company

Our company is experienced in and qualified for the supplying various kinds of high pressure gas cylinders with pressure level B1,B2,B3,A1,C3,D1,D2. Presently, we can supply high pressure seamless steel cylinder, CNG cylinder for vehicle, low pressure LPG welded cylinder, composite cylinder, accumulator shells, welded insulated cylinder, and gas storage special container, aluminum liner fully wrapped with carbon fiber composite cylinder in 30 seriese of 680 sizes.

These cylinders are used to fill with permanent gases, liquefied petroleum gas or compressed natural gas to serve a wide application in chemical industry, metallurgical industry, mechanical industry, petroleum industries, electronic industry, building industry and in the fields of fire fighting, energy, food process, household, medical treatment, cryogenic soldering, mountaineering, diving, mining,scientific research & etc.

Presently our supplies have the approvals of DOT, TUV, CCS, BV, ABS, TC,& LIOYGS. These cylinders also can be designed and processed in strict accordance with the standards of BS, JIS, DIN, EN, KS, ISO, GB(China) or the off-standard from the consumer.

All the manufacturing technology and propertiess test are entirely under the supervision of the thirty-party supervision institute approved by General Administration of Quality Supervision,Inspection and Quarantine of China
